OFFICE & FACTORY
ASSOCIATED COMPANY

Head Office

550-0014
1-22-14 Kita-Horie, Nishi-ku, Osaka City
TEL: 06-6541-9331
FAX: 06-6541-3588

Located at the center of the business district of the commercial city, Osaka, commanding a view of Nikko Hotel on the east and Osaka Dome on the west. It is the best location with great access to various means of transportation.
As the brain of Sanko Shoji Co., Ltd., it works as a facility to offer information that opens the way to the future.

MAP/ Head Office

Higashi Osaka Steel Processing Plant

578-0965
3-1-21, Honjo-Nishi, Higashi-Osaka City, Osaka
TEL: 06-6744-3183
FAX: 06-6744-3180

Higashi Osaka Steel Processing Plant is located near the highway network.
With its uncanny sensitivity to the trend of the times, it endeavors to expand into the new world of “tinplate/TFS” with the motto of “Clean & Communication.”

Facility specification of each line

  Leveler Gang slitter Auto slitter Metal calendar clasp
manufacturing machine
Product type Tinplate/surface treatment Tinplate/surface treatment Tinplate/surface treatment Printed steel plate
Plate thickness 0.15 ~ 0.5mm 0.15 ~ 0.5mm 0.15 ~ 0.5mm 0.15 ~ 0.24mm
Plate width 500 ~ 1050mm 75 ~ 1020mm 450 ~ 1000mm 100 ~ 600mm
Plate length － 1000mm 1000mm －
Internal diameter 406･508 － － －
External diameter 930 ~ 1825mm － － －
Weight max. 15,000kg max. 2,000kg max. 2,000kg －
Cut length 450 ~ 2000mm 450 ~ 1000mm 500 ~ 1000mm 23･25･28･30mm
Number of threads － max. 4 threads max. 6 threads Color
Minimum slit width － 65mm 200mm White/Gray
Black/Red
Green/Dark red
Precision ±0.2mm ±0.2mm ±0.2mm
Line speed max. 120m/min － －
Machine capacity 1000t/month 150t/ month 200t/ month 100million pieces/year
  Leveler Gang slitter
Product type Tinplate/surface treatment Tinplate/surface treatment
Plate thickness 0.15 ~ 0.5mm 0.15 ~ 0.5mm
Plate width 500 ~ 1050mm 75 ~ 1020mm
Plate length － 1000mm
Internal diameter 406･508 －
External diameter 930 ~ 1825mm －
Weight max. 15,000kg max. 2,000kg
Cut length 450 ~ 2000mm 450 ~ 1000mm
Number of threads － max. 4 threads
Minimum slit width － 65mm
Precision ±0.2mm ±0.2mm
Line speed max. 120m/min －
Machine capacity 1000t/month 150t/month
  Auto slitter Metal calendar clasp
manufacturing machine
Product type Tinplate/surface treatment Printed steel plate
Plate thickness 0.15 ~ 0.5mm 0.15 ~ 0.24mm
Plate width 450 ~ 1000mm 100 ~ 600mm
Plate length 1000mm －
Internal diameter － －
External diameter － －
Weight max. 2,000kg －
Cut length 500 ~ 1000mm 23･25･28･30mm
Number of threads max. 6 threads Color
Minimum slit width 200mm White/Gray
Black/Red
Green/Dark red
Precision ±0.2mm
Line speed －
Machine capacity 200t/month 100 million pieces/year
Overhead crane system
  • 15t crane: 2
  • 10t crane: 1
  • 5t crane: 1
  • 3t crane: 1
  • 2.8t crane: 1

MAP/ Higashi Osaka Steel Processing Plant

Nanko Steel Processing Plant

559-0032
5-4-127 Nanko-Minami, Suminoe-ku, Osaka City, Osaka
TEL: 06-6612-5371
FAX: 06-6612-5377

Located in the bay area of Osaka Port, the plant owns private berth that can accommodate 2000-DWL class ships, and responds to diversifying customer needs flexibly with its integrated system that encompasses material procurement, processing, and delivery.

Facility specification of each line

  Leveler Gang slitter Slitter Thin plate slitter
Product type Pickling/cold rolling/surface treatment Pickling/cold rolling/surface treatment Pickling/cold rolling/surface treatment Tinplate/cold rolling
Color/surface treatment
Plate thickness 0.35~2.3mm 0.4~1.6mm 0.35~3.2mm 0.15~0.8mm
Parent metal width 500~1350mm 100~650mm 500~1650mm 100~1000mm
Parent metal internal diameter 508・610
712・762		 508 508・610
712・762		 406・508
Parent metal external diameter 800~2000mm 1400mm 800~2000mm 600~1450mm
Parent metal weight max.20,000kg max.3,300kg max.20,000kg max.10,000kg
Cut length 500~3475mm 150~2000mm － －
Maximum number of threads － － max.16 threads max.23 threads
Minimum slit width － － 60mm 27mm
Precision ±0.3mm ±0.3mm ±0.2mm ±0.1mm
Product internal diameter － － 508 406,508
Line speed max.100m／min max.52.5m／min max.200m／min max.100m／min
Machine capacity 4000t/month 500t/month 4500t/month 500t/month
Tension device － － MD roll
Tension pad		 Mindores roll
Tension pad
  Leveler Mini leveler
Product type Pickling/cold rolling/surface treatment Pickling/cold rolling/surface treatment
Plate thickness 0.35~2.3mm 0.4~1.6mm
Parent metal width 500~1350mm 100~650mm
Parent metal internal diameter 508・610
712・762		 508
Parent metal external diameter 800~2000mm 1400mm
Parent metal weight max.20,000kg max.3,300kg
Cut length 500~3475mm 150~2000mm
Maximum number of threads － －
Minimum slit width － －
Precision ±0.3mm ±0.3mm
Product internal diameter － －
Line speed max.100m／min max.52.5m／min
Machine capacity 4000t/month 500t/month
Tension device － －
  Slitter Thin plate slitter
Product type Pickling/cold rolling/surface treatment Tinplate/cold rolling
Color/surface treatment
Plate thickness 0.35~3.2mm 0.15~0.8mm
Parent metal width 500~1650mm 100~1000mm
Parent metal internal diameter 508・610
712・762		 406・508
Parent metal external diameter 800~2000mm 600~1450mm
Parent metal weight max.20,000kg max.10,000kg
Cut length － －
Maximum number of threads max.16 threads max.23 threads
Minimum slit width 60mm 27mm
Precision ±0.2mm ±0.1mm
Product internal diameter 508 406,508
Line speed max.200m／min max.100m／min
Machine capacity 4500t/month 500t/month
Tension device MD roll
Tension pad		 Mindores roll
Tension pad
Overhead crane system
  • 20t crane: 1
  • 15t crane: 1
  • 10t crane: 2
  • 5t crane: 1
  • 3t crane: 1
Other facilities
  • Shearing machine: 1
  • Direct-reading type crane scale: 2
  • Automatic packing machine: 1

MAP/ Nanko Steel Processing Plant

Tokyo Branch (Sales and Steel Processing Plant)

130-0004
1-1-5 Honjo, Sumida-ku, Tokyo
TEL: 03-3622-4145
FAX: 03-3622-4148

As the axis of our sales strategy, Tokyo Branch expands its trade area to cover whole Japan, and provides a quick response to customers. It plans to completely systemize the whole network from production to distribution.

Facility specification of each line

  Leveler Gang slitter Slitter
Product type Tinplate/surface treatment Tinplate/surface treatment Various steel plates
Plate thickness 0.16~0.6mm 0.16~0.6mm 0.1~0.5mm
Plate width 450~1000mm 1020mm／1200mm 150mm
Plate length － 1000mm －
Internal diameter 406･ 508 － 280~300mm
External diameter 800~1800mm － ~1000mm
Weight max. 15,000kg max. 2,000kg max. 500kg
Cut length 350~1100mm － －
Number of threads － － －
Minimum slit width － － －
Precision Length±0.2mm Width±0.2mm Width±0.2mm
Line speed 90ｍ／min － 100ｍ／min
Line direction Right Left － Right Left
Machine capacity 900t/month － －
  Press
Product type Tinplate/surface treatment
Number of strokes 80spm
Stroke length 100mm
Die height 250mm
Slide adjustment 60mm
Slide size 400x300
Bolster size 600x450x85mm
Stopping time 130ms
Pressure capacity 45Ｔ
Overhead crane system
  • 15t crane: 1
  • 5t crane: 1
  • 2.8t crane: 2

MAP/ Tokyo Branch (Sales and Steel Processing Plant)

Sanko Products Co., Ltd.

578-0965
3-1-21 Honjo-Nishi, Higashi-Osaka City
TEL: 06-6541-9331
FAX: 06-6541-3588
https://www.sanco-p.co.jp/

Since joining Sanko Group in April 2016, it performs a series of production activities from metal mold design to prototype/mass production accommodating customers’ needs.

Facility
  • 110t press: 2
  • 80t press: 1
  • 60t press: 3
  • 45t press: 4
  • 35t press: 3
  • Other small presses: 8
  • NC wire cut
  • Milling machine
  • Lathe
  • Drill press
  • 3 Dimensional coordinate measuring machine, and more.

MAP/ Sanko Products Co., Ltd.
